PL250
Thermocouple Input PLC
- Features
- Thermocouple Input
- Voltage and mA Input
- RTD Input
- Voltage Input
- 16 Digital Input.
- PID Control
- Analog Output
- 12 Relay Output
Thermocouple Input PLC
The PL250 PLC is a versatile and reliable Programmable Logic Controller designed for DIN rail mounting, offering flexible input and output configurations to meet various industrial automation needs. The PL250 is available in two models: the PL250-11AD, which features 4 16-bit thermocouple or RTD inputs, and the PL250-10AD, which provides 4 0-10V inputs or 2 0/4-20mA inputs. Both models come equipped with 16 PNP digital inputs, capable of accepting encoder signals, making them ideal for precise monitoring and control applications.
Key Features and Capabilities:
- Flexible Input Options: The PL250-11AD supports 4 16-bit thermocouple or RTD inputs, while the PL250-10AD offers 4 0-10V inputs or 2 0/4-20mA inputs, providing versatility for various sensor types and applications.
- Digital Input Flexibility: Both models are equipped with 16 PNP digital inputs, including support for encoder inputs, allowing for accurate digital signal processing and control.
- Advanced Output Control: Features two 0-10V analog outputs with P, PI, and PID control, along with 12 relays rated for 5 Amp contacts, enabling precise process control and switching capabilities.
- Expandable I/O: The analog and digital I/O count can be expanded using MCM260 modules, offering additional flexibility for system customization.
- Programmable with PLprog Software: Utilizes PLprog software, allowing programming with ladder diagrams, logic relays, timers, counters, and a range of math and logic functions.
- Real-Time Clock and Battery Backup: Includes a real-time clock and an optional backup battery, ensuring reliable time-keeping and continuous operation even during power interruptions.
