TCT101-1ABC
Process Timer
- Features
- Process Timer
- UL, CE
- 2 x 4 Digit Display
- Memory Card Programmable
- Output 2 Relays 5 Amp
Programmable Panel Mount Process Timer
The TCT101-1ABC Process Timer is a versatile, panel-mount timer designed for precision and flexibility in various industrial applications. With a 4-digit, 2-line display, it offers clear and concise readouts, ensuring easy monitoring and control.Key Features
- Multiple Timer Functions: The TCT101-1ABC supports a range of timer functions, including Timer ON, Timer OFF, Pause Timer, Proportional Timer, and Oscillator. These functions can be customized to meet specific operational needs.
- Dual Relay Outputs: Equipped with two 5A relays, the TCT101-1ABC allows for robust control of external devices and systems.
- Flexible Time Settings: Timer periods can be configured in hundredths, tenths of a second, seconds, minutes, or hours, offering precise control over processes.
- Interrupt Capabilities: The timer can be paused or interrupted via the front touch panel or digital input, providing flexibility in process management.
- Output Toggle Function: The unit can toggle outputs on and off over a set period, enhancing its utility in various applications.
- Multiple Operating Modes: The TCT101-1ABC can be configured in five distinct modes: Timer-ON, Timer-OFF, Pause-Work, Oscillator, and PWM (Proportional Time Output). Each mode allows independent ON-OFF time settings.
- Programming Options: Settings can be programmed using the onboard keyboard or via Labsoftview software. Memory cards are available for quick duplication of settings across multiple devices.
Other options in the TCT101 series are:
The TCT101-2ABC Panel Mount Counter supports a range of counting functions, including totalizing, batch counting, and preset counting.
The TCT101-3ABC Process Tachometer can measure frequencies up to 100kHz, ensuring precise monitoring of high-speed processes.
The TCT101-4ABC-T Modbus Timer, Modbus Counter, Modbus Tachometer is a combination containing a timer, counter, and tachometer and it also has a Modbus RS485 output.
